Trough-type cable tray production equipment

Trough-type cable tray production equipment is a fully automated system integrating roll forming, punching, and cutting processes to manufacture high-quality cable trays efficiently. OverviewTrough-type cable trays are widely used for moderate heat-generating applications and short to intermediate support spans, providing economical support for cable drops and branch runs. The production equipment for these trays is designed to ensure precise dimensions, smooth edges, and consistent quality while accommodating various widths, thicknesses, and lengths suitable for industrial and commercial applications.

Key Components and Processes

Roll Forming Machine: The core of the production line, it continuously shapes metal sheets into the trough profile. Rollers are typically made of durable steel (e.g., Cr12) and undergo heat treatment for long service life. Hydraulic Decoiler: Unwinds steel coils and feeds them into the production line.

The decoiler is hydraulically controlled to expand and shrink the mandrel, ensuring smooth material handling.

CN

C Punching Unit: Precisely punches holes or perforations in the tray for ventilation, heat dissipation, and cable management. Punching molds are made from high-quality materials like SKD11 or Cr12MoV, allowing customizable hole patterns. Cutting System: Integrated cutting modules allow the tray to be cut to desired lengths automatically, maintaining high precision and reducing labor requirements.

PL

C Control System: Centralized control panel enables parameter setting, production monitoring, and fault diagnosis. This ensures forming accuracy within ±0. 2mm and allows semi-automatic or fully automated operation.

Material Handling and Transport: Fast-speed transport tables and servo-controlled feeders ensure continuous, stable operation and precise alignment of metal sheets throughout the production process.

Material Compatibility

The equipment can process a variety of metals, including hot-dip galvanized steel, pre-galvanized steel, stainless steel, aluminum, and cold-rolled steel, with thicknesses ranging from 0. 4mm to 2mm depending on the machine configuration.

Advantages

High production efficiency and reduced labor costsCustomizable tray widths, heights, and lengthsSmooth edges and precise dimensions for safe cable installationIntegrated punching and cutting for ventilation and heat dissipationDurable rollers and PLC control for long-term stable performanceSuitable for large-scale industrial, commercial, and infrastructure projects ApplicationsTrough-type cable trays produced by these machines are commonly used in electrical power plants, factories, office buildings, data centers, and infrastructure projects, providing reliable support and organization for electrical and communication cables.

In summary, trough-type cable tray production equipment offers a fully automated, high-precision solution for manufacturing durable, corrosion-resistant cable trays, combining roll forming, punching, and cutting processes with advanced control systems to meet diverse industrial requirements.
