Common Specifications for Cable Tray Support Arms

Cable tray support arms must comply with standards such as IEC 61537 and DIN 4102, ensuring proper load-bearing, material strength, and installation spacing for safe and durable cable management. Key Standards and GuidelinesIEC 61537 is the internationally recognized standard for metal cable tray systems, covering construction, mechanical strength, corrosion resistance, and electrical continuity. It applies to steel, stainless steel, and aluminum trays, ensuring that support arms can handle cable loads, environmental factors, and external pressures over time.

DI

N 4102 Part 12 specifies fire safety and structural requirements for cable tray installations, including rail height, tray widths, hole proportions, material thickness, maximum permissible cable weight, and fastening spacing.

BS E

N 61537 provides guidance for cable ladder and tray systems in the UK, emphasizing that support arms must be designed to restrain cables safely, withstand short-circuit forces, and maintain system integrity.

Material and Construction

Support arms are typically made from steel or stainless steel, with galvanization or other coatings to improve corrosion resistance. They must be compatible with the cable tray system and capable of supporting the tray without deformation. For fire-rated installations, materials must meet the relevant fire-resistance classifications.

Dimensions and Load Capacity

Tray widths: Commonly 100–300 mm for RS 60 systems. Rail height: 60 mm for standard RS 60 trays. Support arm lengths: Pendant brackets up to 900–1500 mm; cantilever brackets for wall or ceiling mounting vary from 100–300 mm.

Fastening: Typically two mushroom head bolts per tray connection; threaded rods (M10) may be used for ceiling suspension. Spacing: Horizontal and vertical changes of direction must be supported within 150 mm of joints. Maximum permissible cable dead weight and fastening spacing are defined by the standard and must be adhered to for safety.

Installation Considerations

Support arms can be mounted on ceilings, walls, or floors using cantilever or pendant brackets. For inclined trays, specialized fastenings like KLAF 6 may be used. All changes in direction or elevation must be supported immediately to prevent sagging or stress on the tray system.

Support arms should be installed by competent personnel familiar with electrical installation practices and safety requirements.

Summary

Cable tray support arms are critical components that must meet mechanical, fire, and corrosion standards. Compliance with IEC 61537, DIN 4102, and BS EN 61537 ensures that trays are safely supported, maintain electrical continuity, and withstand environmental and operational stresses. Proper material selection, correct dimensions, and adherence to installation spacing are essential for long-term reliability and safety in industrial and commercial installations.
