Types of Stainless Steel Mesh Cable Trays

Stainless steel mesh cable trays are versatile, corrosion-resistant systems used for routing and supporting electrical, data, and communication cables in various environments. Common Examples and FeaturesJLH Stainless Steel Wire Mesh Cable Trays These trays use a wire basket with 3. 5–6 mm diameter stainless steel wires, available in widths from 200 to 500 mm, heights from 50 to 200 mm, and lengths from 300 to 3000 mm.

They are ideal for small-diameter cables, particularly data communication lines, and can be bent or cut to accommodate curves, slopes, and tees. Optional covers are available for added protection, and the trays can be mounted overhead, on walls, or under floors.

Apex S

S Basket Cable Trays Designed for data centers, telecom facilities, and industrial plants, these trays provide excellent ventilation, easy cable access, and high strength while remaining lightweight. They are made from stainless steel grades 304 or 316, offering superior corrosion resistance for harsh environments. Their open mesh design allows for passive cooling and flexible cable management, making them suitable for frequent cable changes.

Industrial

River Stainless Steel Mesh Trays These trays come in kits with multiple sections, such as ten 10-foot sections of 304 stainless steel, with widths of 4–6 inches and depths of 2–4 inches. They are suitable for network, AV, fiber optic, and power cabling, providing NEC-approved usage and modular expandability. Mesh designs promote airflow and heat management, while quick-release components simplify installation.

Mohn Multi-

Cable Mesh Trays These trays are designed for hygienic cable routing in industries like food processing and pharmaceuticals. The robust stainless steel construction protects cables from external influences, and the smooth surface allows easy cleaning. They are ideal for mounting on railings or pillars, combining flexibility with protection for multiple cable harnesses.

Direct

Industry Stainless Steel Mesh Trays Products like EASYCONNECT® and Electrix® wire basket trays use stainless steel 304, 316, or 316L with mesh wire diameters around 4 mm. They feature integrated fixing systems for quick installation, adjustable configurations for field obstructions, and safety edges for cable support. These trays are suitable for industrial and commercial applications requiring corrosion resistance and high load capacity.

Key Advantages

Corrosion Resistance: Stainless steel ensures durability in indoor and outdoor environments, including chemical or humid conditions. Ventilation: Open mesh design prevents heat buildup, extending cable lifespan. Flexibility: Trays can be cut, bent, or customized to fit complex layouts.

Ease of Installation: Lightweight construction and modular components allow quick deployment and future modifications. Hygienic and Aesthetic: Smooth surfaces and clean appearance make them suitable for visible installations and hygienic environments. These examples demonstrate the versatility of stainless steel mesh cable trays across data centers, industrial plants, commercial buildings, and specialized hygienic applications.
